ICASP3540-20A
3.45 – 4.0 GHz 20 W High-Efficiency Power Amplifier
ICASP3540-20A is a high-efficiency DPD-friendly power amplifier designed for 5G NR FR1 band n77. This power amplifier is fully matched at input and output. It is realized in GaN technology and overmolded in a compact 26-pad 6 × 10 mm2 LGA package.
This amplifier is part of iCana’s high-efficiency 20 W PA RF product family designed for wireless infrastructure.
Key Features
- Frequency range: 3450 – 4000 MHz
- High efficiency: PAE = 40% at 33 dBm POUT (avg)
- High linearity: ACLR < -50 dBc at 33 dBm POUT (avg) with digital pre-distortion (5G signal, BW = 200 MHz)
- Wide instantaneous bandwidth: 200MHz
- High power gain: 30 dB
- 50 Ω matched input and output
- Drain voltage: VDD = 28 V
- Compact 6.0 × 10.0 x 1.1 mm3 thermally enhanced LGA package
Typical Applications
- Small cells for wireless communications infrastructure
- Repeaters / DAS
- General purpose wireless
| Part Number | Frequency Range [GHz] | Availability |
|---|---|---|
| ICASP3338-20A* | 3.3 - 3.8 | Contact Us |
| ICASP3540-20A | 3.45 - 4.0 | Sampling Now |
| ICASP4450-20A* | 4.4 - 5.0 | Contact Us |
*Coming Soon
