8 W Wide-Bandwidth Power Amplifiers
Key Product Line Characteristics
- Wide operational bandwidth
- High Pout: >34 dBm across the entire frequency range
- High gain: >30 dB
- High efficiency at target operating power
- 5×5 mm2 package, part of pin to pin compatible family
| Part Number | Frequency Range [GHz] | Gain [dB] | Operating Power [dBm] | PSAT [dB] | Availability |
|---|---|---|---|---|---|
| ICADP4251-8 | 4.2 - 5.1 | 44 | >34 | >37 | Sampling Now |
| ICADP3251-8 | 3.2 - 5.1 | 34 | >34 | >37 | Sampling Now |
| ICADP1625-8* | 1.6 - 2.5 | >30 | >34 | >38 | Contact Us |
*Coming Soon
