Drones (Unmanned Autonomous Vehicles (UAVs)) have become critical in everyday life and on the battlefield and are becoming more important and more broadly used every day. UAVs require robust, reliable operation across a wide range of frequencies.
Tactical drones in particular must be high power and high linearity to allow long range transmissions, must be efficient to allow long battery operation, and must be highly frequency agile to counter jamming attempts.
iCana wide-bandwidth drone PAs exhibit these exceptional qualities. In addition, iCana's high-efficiency sub-6 GHz Wireless Infrastructure PAs can also be used in drone applications, when high efficiency is critical and the absolute widest bandwidth is not required.
iCana's current and upcoming drone PA portfolio includes a family of 8W (peak) wide-bandwidth PAs and a family of 16W (peak) wide-bandwidth PAs. The 8W PAs are pin-to-pin compatible with each other as well as iCana's 8W Wireless Infrastructure PAs. The 16W PAs are pin-to-pin compatible with each other. These PAs are designed in a high–power GaAs process, avoiding the negative aspects of LDMOS and GaN designs, including a negative gate voltage and high drain voltage requirements.
For more information about iCana Drone Communication products and developments, contact us at sales@icana-rf.com
| Part Number | Frequency Range [GHz] | Gain [dB] | Operating Power [dBm] | PSAT [dB] | Availability |
|---|---|---|---|---|---|
| ICADP4251-8 | 4.2 - 5.1 | 44 | >34 | >37 | Sampling Now |
| ICADP4251-8B | 4.2 - 5.1 | 34 | >34 | >37 | Sampling Now |
| ICADP3251-8 | 3.2 - 5.1 | 34 | >34 | >37 | Sampling Now |
| ICADP1625-8* | 1.6 - 2.5 | >30 | >34 | >38 | Contact Us |
*Coming Soon
| Part Number | Frequency Range [GHz] | Gain [dB] | Operating Power [dBm] | PSAT [dB] | Availability |
|---|---|---|---|---|---|
| ICADP3251-16* | 3.2 - 5.1 | >30 | >37 | >41 | Contact Us |
| ICADP1625-16* | 1.6 - 2.5 | >30 | >37 | >41 | Contact Us |
*Coming Soon
